10K Potentiometer Module
Product Overview
This module features a 10KΩ rotary potentiometer mounted on a compact PCB, designed to provide an adjustable analog voltage output. It acts as a voltage divider, making it ideal for controlling analog inputs in microcontrollers and embedded systems.

With a simple 3-pin interface, this module allows users to easily vary voltage levels by rotating the knob.

Key Features
  • 10KΩ Linear Potentiometer
  • Analog Output (Variable Voltage)
  • 3-Pin Interface (VCC, GND, OUT)
  • Smooth Rotary Adjustment
  • Compact PCB Design
  • Direct Microcontroller Compatibility

Use Cases
  • Analog input testing (Arduino / ESP32 / FPGA ADC)
  • Brightness control (LED dimming via PWM input)
  • Motor speed control (via controller input)
  • Menu navigation (as rotary input substitute)
  • Calibration and tuning circuits
  • Sensor simulation (mock analog signals)

Advantages
  • Simple analog control without coding complexity
  • Ideal for learning ADC concepts
  • Quick testing tool for embedded systems
  • Reliable and reusable module
  • Clean and stable output signal

Application Examples
  • Control LED brightness using PWM
  • Adjust servo position manually
  • Simulate sensor values (temperature, light, etc.)
  • Tune threshold values in comparator circuits

Package Includes
  • 1 × 10K Potentiometer Module
  • 1 x 3 Pin Header(unsoldered)

Compatibility
Works with:
  • Arduino (UNO, Nano, Mega)
  • ESP8266 / ESP32
  • Raspberry Pi (with ADC)
  • FPGA boards (via ADC like XADC)
  • Any analog input system

Notes:
  • Output is analog, not digital
  • Ensure correct VCC (3.3V or 5V as per system)
  • Avoid applying voltage beyond rated limits
  • Mechanical rotation limit ~270° (do not force)

Weight = 2 grams
Dimensions = 1.5 cm x 1.2 cm x 1.2 cm

10K Potentiometer Module

₹35.00Price
Quantity
  • Parameter Value
    Resistance Value 10KΩ
    Type Linear Potentiometer
    Output Analog Voltage
    Operating Voltage 0V – VCC (typically 3.3V/5V)
    Interface 3-Pin Header
    PCB Material FR4
